Specification:

Max.continue discharge current (A)：  150
Max.pulse discharge current ( A)：  200A 30S
Max.continue charge current ( A )：  100
Cycle life(+25℃ 0.2C 100%DOD ) ：  6000
Terminal：  M8
Storage temperature：  0℃ ~ 30℃
Storage duration：  6 months at 25℃
BMS communication：  CAN/RS485/RS232
Safety standard ：  UN38.3, MSDS
IP degree：  IP20
Max. number of parallels supported：  16 ( (5KWH-90KWH available))

Protection:

Overcharge protection, Overdischarge protection, Overcurrent protection, Shortcircuit protection, Overtemperature protection

Ambient:

Working Temperature:  -10℃ - +50℃
Humidity:  0-95% (no condensation)
Sea Level(m):  ≤1500

Dimension:

L*W*H  (products size) mm:  770*492*203mm
L*W*H  (package size) mm:  815*544*256mm(UN carton)
Weight (NW Kg):  68.0Kg
Weight (GW Kg):  72.0Kg
20FT QTY( UNIT):  224

■ Feature
► More than 6000 times charge/discharge cycles life
► With the overcharge and over-discharge protection function
► With the overcurrent and shortcircuit protection function
► With the overtemperature protection function
► Tower case .strong appearance.
► Application for off-grid solar power system
► Excellent standby self-consumption as low as 4mA
► Intelligent BMS equipped inside to maintain the battery always work in the best condition
► Within solar inverter Modbus-485 communication protocol
► Automatically output cut off after 30 days with no charge and discharge to ensure security, also can cut off output by manual operation
► 5 years warranty, 8-12 years lifetime, LiFePO4 battery, more stable and safe

■ Application
Storage solar system, UPS power bank, Inverter power bank, Railway power bank, Telecommunication power system, Medical electronics, Commercial finance, Security communications, Transportation logistics, and so on.
